| RETAINING RING BORE DIAMETER – Dec.equiv.inch |
0.866 |
| RETAINING RING BORE DIAMETER – Approx.fract.equiv.inch |
– |
| RETAINING RING BORE DIAMETER – Approx.mm |
22.0 |
| RETAINING RING DIMENSIONS – Free Dia. – D |
0.961 |
| RETAINING RING DIMENSIONS – Free Dia. – tol. |
±.015 |
| RETAINING RING DIMENSIONS – Thickness – t |
0.042 |
| RETAINING RING DIMENSIONS – Thickness – tol. |
±.002 |
| RETAINING RING DIMENSIONS – lbs. |
2.0 |
| RETAINING RING GROOVE DIMENSIONS – Diameter – G |
0.92 |
| RETAINING RING GROOVE DIMENSIONS – Diameter – tol. |
±.003.004 |
| RETAINING RING GROOVE DIMENSIONS – Width – W |
0.062 |
| RETAINING RING GROOVE DIMENSIONS – Width – tol. |
+.003-.000 |
| RETAINING RING GROOVE DIMENSIONS – d |
0.027 |
| C1 |
0.54 |
| C2 |
0.59 |
| ThrustLoad |
5100.0 |
| L (mx) |
0.16 |
| b – |
0.081 |
| h (mn) |
0.06 |
